Modern House Plan 30×45 Meter with 5 Bedrooms

Modern-House-Plan-30x45-Meter-with-5-Bedrooms-front-3d

Modern House Plan 30×45 Meter with 5 Bedrooms

Modern House Plan 30×45 Meter with 5 Bedrooms. Casa Luanda is a large, sophisticated and modern house, with architecture characterized by straight lines, well-defined volumes with large spans and openings.

Excellent option, especially for those who prefer large rooms and suites and special environments such as: home theater, gym, wine cellar and gourmet space to enjoy the house with intensity.

In addition to the internal gardens, there are rooms with double height ceilings, providing differentiated lighting and ventilation. The ground floor has service and support environments for the maid’s room, laundry and storage.

Entrance hall, living, dining and intimate rooms, kitchen, 2 washrooms, home theater, gourmet space facing the pool deck.

For access to the upper floor, a staircase was designed with the option of deploying an elevator that lead to the intimate area, gym, bar and library in addition to 4 suites with dressing room. Really… 969m2 of pure dream!

See more in the plans below:

Modern House Plan 30x45 Meter with 5 Bedrooms layout ground floor plan
Modern House Plan 30x45 Meter with 5 Bedrooms layout first floor plan

Modern House Plan 30×45 Detailing

Modern home with a loft 30×45 Meter, 5 Beds, 7 baths, mini fridge, mini range, & stacked wash/dryer.

Building size: 23 Meter wide, 34 meter deep (including porch & steps)
Main roof: Terrace concrete or zine tile
Cars Parking is out side of the house
Living room
Bedroom: 5 Bedrooms
Bathroom: 7 Bathrooms
Dining room with Kitchen
Washing room

Modern House Plan 30x45 Meter with 5 Bedrooms layout master plan

Buy this House Plan at plantasdecasas.com

Modern House Plan 30×45 INCLUDE:

Elevations
Exterior / Interior Dimension Plan
Floor / Ceiling Framing Plan
Roof Framing Plan
Cross Section
Door & Window Schedule
Lighting Plan
Ideas for modifications
An estimated materials list for the doors, windows, and general wood framing.

You are purchasing the PDF file for this plan. Print it out whenever you like, as many times as you like.
Plan prints to 1/4″ = 1′ scale on 24″ x 36″ paper.

CUSTOM PLANS:
Unfortunately I’m unable to do custom plans at this time.

DISCLAIMER:
These plans were produced by myself and were not prepared by nor checked by a licensed architect and/or engineer.
I do not represent nor imply myself to be a licensed architect and/or licensed engineer.
Enjoy these plans but use them at your own discretion.

Delivery Instant Download

Your files will be available to download once payment is confirmed. Here’s how.
I don’t accept returns, exchanges, or cancellations. But please contact me if you have any problems with your order.
View shop policies
